75x236 - 2 Doors + 4 Drawer Fronts - Laminex - PAX
← Back to IKEA PAX

75x236 - 2 Doors + 4 Drawer Fronts - Laminex - PAX

1. Profile
2. Finish
3. Colour
From $510.00 AUD
Tax included. Shipping calculated at checkout.

Plain Laminex Natural Finish

Specifications

Set includes2 x Doors + 4 x Drawer Fronts
FitsIKEA PAX frame 75cm wide x 236cm high
Thickness18mm
ProfilePlain
FinishLaminex Natural Finish, Laminex AbsoluteMatte Finish, Laminex AbsoluteGrain Finish

Product details

  • Customea Exclusive. Turn a standard IKEA PAX frame into a built-in style wardrobe with two full doors above and four drawers below, a layout IKEA doesn't offer.

    • Laminex Natural Finish

    The Laminex Natural Finish Doors, Drawers & Panels have identical board on both sides, and all edges are finished with matching edgebanding.

    Laminex Natural & Flint Colour Guide (PDF)

    Laminex AbsoluteMatte Finish

    The AbsoluteMatte Laminate Doors, Drawers & Panels have one side and the edges in the Absolute Matte finish of your choosing, the other side is black, white or grey in a standard melamine finish (pre-set and not selectable).

    The exception are panels labeled as Double Sided- these will have matching laminate colour front & back.

    Laminex AbsoluteMatte Backing Guide (PDF)

    Laminex AbsoluteGrain Finish

    The AbsoluteGrain Laminate Doors, Drawers & Panels have identical board on both sides, and all edges are finished with matching edgebanding.

    On Absolute Grain colours the grain runs in a vertical direction on all items (except for the plinths and the large Back-of-Kitchen-Island Panel, over 120cm W. These will have the grain running horizontally). Absolute Matte and Natural are solid colours with no grain direction.

    • Doors, Drawers and Panels are finished with matching edgebanding. Plinths are not edged.
  • Doors come with hinge holes pre-drilled. Drawer fronts fix onto the IKEA KOMPLEMENT drawer fronts.
  • Not included, buy from IKEA: 1 x PAX frame 75cm wide x 236cm high, 4 x KOMPLEMENT drawers with front (75cm), PAX door hinges.
  • You will also need 20mm screws (6 per drawer front) and 2 clamps to fit the drawer fronts (not included). Handles not included.

    • Installation:

  • 1. Assemble the PAX frame and fit the 4 KOMPLEMENT drawers with their IKEA fronts.
  • 2. Hang the two doors first using the IKEA hinges and adjust them so they sit level.
  • 3. Work from top to bottom. Clamp the top drawer front to the IKEA drawer leaving a 3mm gap below the doors, pre-drill the IKEA front from inside, then fix it through the IKEA front with 20mm screws (6 per front: corners plus centre top and bottom). On routed profiles keep the screws on the flat border and do not over-tighten.
  • 4. Clamp the second drawer front leaving a 3mm gap to the drawer front above, pre-drill and screw, then repeat for the remaining two. The deepest drawer front goes at the bottom.
  • 5. Check all gaps are even and adjust the doors if needed.
  • Download the step-by-step installation guide (PDF)
